Name: XUNNUO Customized Flush Valve Float Automatic Assembly Machine
Availability: InStock

XUNNUO Customized Flush Valve Float Automatic Assembly Machine

Special automatic assembly machine for toilet drain valve float cups
Equipped with PLC control system and user-friendly touch screen for intuitive & stable operation
Configured with high-precision servo modules and pneumatic grippers for precise assembly
Matched with vibratory bowl feeders to realize steady parts feeding
Quality inspection implemented after every assembly procedure
Built-in automatic rejection function for defective products
Ensures high consistency of finished products
Maintains stable production efficiency
Perfect equipment for large-batch mass production

Brand :
XUNNUO TECHNOLOGY
Application :
Flush Valve Float Assembly
Efficiency :
550-600 PCS/H
Control System :
PLC (Multiple brands available)
Operator :
One operator for multiple machines
Customizable :
We provide customized assembly and testing equipment for various toilet tank components, including flush valves, fill valves, push buttons and more

Inquiry Now

Working Process:

Key Base Feeding → Spring Feeding & Assembly → Key Pin Feeding & Assembly → Assembly Inspection → Defective Parts Rejection → Rod 1 Assembly → Rod 2 Assembly → Finished Product Discharge → Good/Defective Product Sorting

Machine Parameters:

Parameter	Specification
Overall Dimensions	3800 × 2600 × 1800 mm
Noise Level	Operating noise < 85 dB (excluding the vibratory feeder)
Power Supply	Voltage: 220 V, Power: 3 kW
Air Source	Air pressure: ≥ 0.5 MPa, Air consumption: ≈ 200 L/min
Equipment Efficiency	550–600 pcs/h (pieces per hour)

Machine Advantages:

High Production Efficiency: Achieves an output of 550–600 pieces per hour, ensuring stable and consistent assembly quality.
User-Friendly Control System: Features PLC control and a touchscreen interface for intuitive operation, parameter adjustment, and real-time production monitoring.
Precision Assembly Performance: Equipped with servo modules, pneumatic grippers, and high-precision vibratory feeders for accurate and reliable component handling.
Built-In Quality Assurance: Includes in-line inspection at every assembly step, with automatic rejection of defective parts to prevent non-conforming products from entering the final stage.
Low Noise Operation: Maintains a working noise level below 85 dB (excluding vibratory feeders), suitable for continuous production in sanitary ware facilities.
Space-Efficient Design: Compact overall dimensions of 3800 × 2600 × 1800 mm, optimized to minimize floor space requirements.
Reliable Utility Requirements: Operates on a standard 220V / 3kW power supply, requiring only 0.5 MPa+ air pressure with low consumption (≈200 L/min) for easy integration into most factory environments.
